Place of Origin : Shandong china
Brand Name : Keda
Price : $5,000/sets >=1 sets
Certification : CE 9001
MOQ : 1
Video outgoing-inspection : Provided
Machinery Test Report : Provided
Core Components : Engine, Pump
Type : Mini gold washing dredger
Power Type : Diesel
Dredging Depth : 1.5 m
Draught : 40 inch
Dimension(L*W*H) : 2300*1500*1000mm
Weight : 100 KG
Warranty : 1 year
After-sales Service Provided : Engineers available to service machinery overseas
Suction Head : 8m
Power : 8HP
Usage : panning & fossick(gold)
Head : 31m
Fixed Agitating Chute : customized
Color : customized
Water Flow : 33m3/h
Diesel Rotate Speed : 3600r/m
Applicable Industries : Energy & Mining
Showroom Location : Philippines, South Africa
Marketing Type : New Product 2020
Warranty of core components : 1 Year
Condition : New
Mini gold dredger with a gold chute for high recovery rate, powered by a famous engine with pump, float is made up of high strength and light weight plastic. There are advantages that small in size, easy to transportation , it is widely used for working of gold mining in mini river channel.
| Mini Gold Dredger | |||
|---|---|---|---|
| Model | QFT3-2 | QFT4-3 | QFT5-3 |
| Dimension | 2300*1500*1000mm | 2500*1500*1000mm | 2500*1500*1000mm |
| Diesel | |||
| Model | RZ170F | RZ178F | RZ186FA |
| Power | 5hp | 7hp | 12hp |
| Rotate Speed | 3600rpm | 3600rpm | 3600rpm |
| Fuel Consumption | ≤284g/Kw·h | ≤283g/Kw·h | ≤280g/Kw·h |
| Fuel Capacity | 2.65L | 3.3L | 5.5L |
| Pump | 1 set | 1 set | 2 sets |
| Dimension(L*W*H) | 550*450*450mm | 550*470*450mm | 550*500*480mm |
| Pump Diameter | 50mm(2inch) | 80mm(3inch) | 100mm(4inch) |
| Water Flow | 33m³/h | 60m³/h | 80m³/h |
| Head | 30m | 30m | 25m |
| Dredging depth | 0.5-0.8 m | 0.5-0.8 m | 1.5 m |
| Work Capacity | 5m³/h | 8m³/h | 13m³/h |
| Gold Chute | |||
| Dimension(L*W) | 400*1500mm | 500*1700mm | 500*1700mm |
| With gold felt | With gold felt | With gold felt | |
| Float | |||
| Dimension(L*W*H) | 1600*395*370 | 1600*395*370 | 1600*395*370 |
| Suction Pipe | 3inch | 4inch | 5inch |









Qingzhou Keda Mining Machine Co., Ltd. is a re-registered modern formal company of the shareholders. Our company mainly produces iron selecting equipment, all kinds of dredgers, dredging equipment, sand washing and sand making equipment, gold panning equipment, magnetic separating, crusher and so on. There are more than a hundred kinds of products. We design and produce various products according to customers' requirements and geographical conditions. Our company is a modern large-scale mineral processing equipment manufacturer specialized in the research and development, engineering design, production, installation, commissioning and after-sales service.
We pay attention to the development of scientific research, and form strategic partnerships with major research institutions. We have established good cooperation with some import and export trading companies and Shandong Magnetic Equipment Research Institution. We have a CAD Aided Design R&D Center and a physical mineral processing laboratory, which can work out reasonable and practical solutions according to customers' technical requirements and work sites. We have established and improved the file for our equipment and service system. We concentrate on customers' feedback to constantly improve our products to meet customers' different needs.
Honesty and credit is our business value and "Customer First, First-Class Quality and First-Class Service" is our business life.
We have owned a good reputation both in domestic and overseas markets. You are invited to create a brilliant tomorrow together!

|
|
Mini Gold Dredger 8HP Power 3600r/m Rotate Speed for Gold Mining Images |
